Our MLRD10 mobile loading ramp/mobile docking ramp is the ideal solution for efficiently loading and unloading trucks or containers using forklifts without fixed loading infrastructure. Whether outdoors, on changing construction sites, or in mobile work environments – it offers a reliable loading option.
Stable construction for heavy loads
A manually operated hydraulic pump makes it possible to adjust the height of the ramp effortlessly, and this can be done by just one person. This allows the ramp to be quickly and easily adjusted to various truck and container heights with a lifting range of 1,100–1,800 mm. This allows for seamless forklift access, resulting in faster goods handling and thus saving time and money.
With a load capacity of up to 10,000 kg and impressive dimensions of 2,100 mm x 11,300 mm x 1,100 mm, this ramp is equipped for the toughest tasks. The sturdy material ensures that the ramp is not susceptible to deformation. Thanks to the integrated trailer hitch, the 2,600 kg mobile loading ramp can be easily transported to the next location on the company premises using a tractor.
Security features for smooth processes
The permanently mounted safety chains and robust supports, as well as brake blocks on the ramp, ensure secure positioning even under full load. The non-slip surface mesh structure ensures optimal grip even in adverse weather conditions such as rain and snow. An integrated railing supports safe entry and prevents accidents caused by falls or slipping.
With our mobile loading ramp MLRD10, you not only increase your throughput but also ensure safe and efficient operations at all times.
Please familiarize yourself with the applicable national regulations in the country of use before commissioning. Commissioning and the selection of suitable personnel for the operation are the responsibility of the commissioning company.
Stable construction for heavy loads
A manually operated hydraulic pump makes it possible to adjust the height of the ramp effortlessly, and this can be done by just one person. This allows the ramp to be quickly and easily adjusted to various truck and container heights with a lifting range of 1,100–1,800 mm. This allows for seamless forklift access, resulting in faster goods handling and thus saving time and money.
With a load capacity of up to 10,000 kg and impressive dimensions of 2,100 mm x 11,300 mm x 1,100 mm, this ramp is equipped for the toughest tasks. The sturdy material ensures that the ramp is not susceptible to deformation. Thanks to the integrated trailer hitch, the 2,600 kg mobile loading ramp can be easily transported to the next location on the company premises using a tractor.
Details:
- Model: MLRD10
- Max. load: 10,000 kg
- Dead weight: 2,600 kg
- Dimensions: 11,300 mm x 2,100 mm x 1,100 mm
- Height adjustment: via manually operated hydraulic pump
- Height adjustment range: from 1,100 mm – 1,800 mm Height adjustable
- Railing height: 200 mm (40*60*3mm rectangular tube)
- Main structure: 160*80*5 rectangular tube, plus middle auxiliary beam
- Subframe structure: 100*50*4 Rectangular tube
- Hydraulic cylinder: Φ80*Φ50 (2 pcs.)
- Hydraulic hose: 32Pma high-pressure oil line
- Mobile rubber wheels: 600-9 solid rubber tires
- Bridge and container: The bridge body is welded with hooks and fastened with steel chains
