Description Read moreRead less
EMSA250PULS MIG/MMA/WEDGE INVERTER WELDING SYSTEM
The HOLZMANN EMSA250PULS enables electrode/gas shielded arc welding and TIG welding in a single device. Display and further customization of the operation.
Highlights
- Advertisement
- Connection for spool gun
- MMA (electrode) welding:
- 20 - 200 A (welding current range)
- MIG (shielded gas) welding:
- 60 - 250 A
- Welding wire thickness Ø0.8|1.0|1.2mm
- Burn-back time: 0.5 s
- Soft start speed: 1 - 13 m/min
- Spot welding time: 0.1-9.9s
- Spot welding pause time: 0.1-25.5s
- Gas pre-flow time: 0- 10s
- Gas post-flow time: 0.1-50s
- MIG double-pulse welding: Pulse frequency: 0.5-5 Hz
- TIG welding:
- 10 - 250 A
- Pulse frequency: 0.1 - 99 Hz
Scope of delivery : Earth clamp 300A (3m), electrode bar 300A (2m), MIG welding torch (3m), gas hose length (2m), pressure reducer
Technical details
General measurements
Dimensions in mm 560 x 240 x 460
Swiss technology
Input voltage 230 V / (50-60 Hz)
Input power capacity in KVA 10
Weight
Gross weight in kg 23
Net weight in kg 20
Shipping dimensions
Packaging width in mm 380
Packaging length in mm 520
Packaging height in mm 390
General data
EAN code
9120132140380
